Barco ClickShare Hub Pro ولوحة تحكم – نظام غرف مؤتمرات فيديو متميّز للاجتماعات الهجينة في MTR

Barco ClickShare Hub Pro and Control Panel Kit Specifications: Manufacturer: Barco Model: ClickShare Hub Pro and Control Panel Kit3 Control Panel: 10.1″ capacitive touchscreen, anti-fingerprint, anti-glare, up to 4 touch points Video outputs: HDMI-1: UW5K WUHD (5120*2160) @30Hz HDMI 2.0 HDMI-2: 4K UHD (3840*2160) @30Hz HDMI 2.0 eDP (Control Panel): HD (1280*800) @60Hz DP 1.4 Video inputs: 4K UHD (3840*2160) @30Hz HDMI 2.0 Audio output: USB-A 2.0/3.0 USB-C 2.0/3.0 HDMI 2.0 ClickShare Buttons: 2× ClickShare Button 5th Generation ClickShare App: Desktop Maximum sources simultaneously on screen: 1 Noise Level: Maximum 25 dBA @ 30°C Wireless transmission protocol: IEEE 802.11 a/b/g/n/ac/ax/be and IEEE 802.15.1 BT 5.3 Reach: Max. 30m (100ft) between ClickShare Button and ClickShare Base Unit Network connection: LAN Hub Dimensions (H×W×D): 37 × 180 × 180 (mm) ClickShare 10M 20W USB-C AOC Cable (Directional): 10M / 6mm, USB-C 3.2 Gen1, DP 1.4 Power supply: USB Type-C, 100-240V~50-60Hz 2.4A, DC Output 180W max (36V 5A) / 140W (28V 5A) / 100W (20V 5A) / 45W (15V 3A) / 27W (9V 3A) / 15W (5V 3A) ClickShare Hub Pro is a premium, modular wireless video conferencing system for enhanced hybrid meetings. The Hub Pro works with the ClickShare Control Panel and it enables participants to start their meeting with a simple tap. Sharing 4K content is just as easy with two next-gen ClickShare Buttons . Paired with dual display support, the Hub enhances engagement and collaboration. For IT managers and integrators, ClickShare Hub Pro offers a customizable solution for all room types. Built on the Microsoft Device Ecosystem Platform (MDEP), it guarantees enterprise-grade security and compliance. Barco ClickShare Hub Pro and Control Panel Kit Key Features: Wireless presentation: 4K content sharing with 2 next-gen ClickShare Buttons with USB-C DisplayPort™​. 2-in-1 Tray for your ClickShare Buttons. Intuitive Control Panel for one-tap start to your hybrid meeting. Dual display support. Secure by design, cloud-managed, and built on the Microsoft Device Ecosystem platform (MDEP). Sustainable product with Barco Eco label A+. Works as part of a room system bundle certified for Microsoft Teams. Barco ClickShare Hub Pro and Control Panel Kit Resources: ClichShare Hub Pro and Control Panel Kit Datasheet: View PDF
