AX86R هاتف IP محمول بـ Wi-Fi للمؤسسات يلبّي احتياجات الاتصال اللاسلكي؛ بحماية IP67 ضد الماء والغبار ومقاومة السقوط من ارتفاع 1.8م.
تحديد موديل AX86R وطلبه للمشروع
هذه الصفحة تخص Yealink AX86R – هاتف Wi-Fi متين، شاشة LCD ملونة 2.4 بوصة، 4 حسابات SIP، Bluetooth 5.0، Wi-Fi 6، IP67، تحدّث حتى 13 ساعة من Yealink، ورمز الطلب المحدد هو AX86R. عند طلب عرض السعر، استخدم هذا الرمز كاملاً لتفادي الخلط مع المقاسات أو الألوان أو التوصيلات أو الإصدارات القريبة ضمن فئة حلول هواتف IP.
معلومات تساعدنا في إعداد عرض أدق
- الكمية المطلوبة من الموديل AX86R
- موقع المشروع وموعد التوريد المتوقع
- الحاجة إلى التركيب أو البرمجة أو التكامل مع نظام قائم
- الملحقات أو التراخيص أو الحوامل والكابلات المطلوبة
تفاصيل المنتج والمواصفات
Yealink
AX86R
Ruggedized Color Screen Wi-Fi Phone Specifications:
Manufacturer:
Yealink
Model:
AX86R
Part Number:
1301221
Screen:
2.4" 240x320 TFT Color Screen
Accounts:
4 VoIP Accounts
Conference Call:
Local 5-way conferencing
Interface:
1× 3.5 mm headset jack, 1× Type-C port
Feature Keys:
2 soft keys, Navigation key and OK key
7 function keys:
dial, hang up, handsfree, voice message, mute, call transfer
Wi-Fi:
Built-in dual-band Wi-Fi
Bluetooth:
Built-in Bluetooth 5.0
Safe drop height:
1.8 m
Protection rating:
IP67
Battery:
3100mAh, Rechargeable Lithium-ion Battery, 3.7V, 11.47Wh
Up to 13-hour talk time (Laboratory data)
Up to 300-hour standby time (Laboratory data)
Power adapter:
AC 100~240V input and DC 5V/2A output
The
AX86R
is an enterprise portable Wi-Fi IP color screen phone that meets wireless communication needs.
AX86R
meets the IP67 protection standard, effectively providing waterproof, dustproof, and 1.8-meter drop-proof capabilities. The
AX86R
supports registering up to 4 SIP accounts, 5-way local conferencing, and features a 2.4-inch color display. It integrates Yealink's Optima HD Audio and Smart Noise Cancellation technology to deliver exceptional audio quality and clear voice communication. It is equipped with a built-in Bluetooth 5.0 module and a dual-band 2.4G/5G Wi-Fi 6 module, combined with advanced seamless roaming technology, allowing you to stay ahead in the ever-evolving wireless era. In addition,
AX86R
is equipped with a 3100mAh battery, providing a talk time of 13 hours and a standby time of 300 hours. It is widely used in various wireless scenarios such as healthcare, manufacturing, warehouses, transportation, and education.
Yealink
AX86R
Ruggedized Wi-Fi Headset Key Features:
IP67-rated waterproof and dustproof, dropproof up to 1.8 meters
Up to 13-hour talk time (Laboratory data)
Up to 300-hour standby time (Laboratory data)
Red emergency button and automatic alarm
Antibacterial design, chemical cleaning resistant
Dual Band 2.4G/5G Wi-Fi 802.11 a/b/g/n/ac/ax
Support IEEE802.11k/v/r roaming
Bluetooth 5.0 for headset
HD audio, noise cancellation and acoustic shield
TRANS and Mute keys
Up to 4 SIP accounts, local 5-way conferencing
No Perception Upgrade
Type-C charging
Wall mountable
Support YDMP/YMCS
Yealink
AX86R
Wi-Fi IP Phone Resources:
Yealink AX86R Datasheet:
View PDF
Display
2.3”, Graphical LCD
Connectivity
Bluetooth 4.2, Dual band 2.4G/5G Wi-Fi
Protection
Disinfectant Resistant, Dust Resistant, IP54 Rating, Scratch Resistant
Battary
1460 mAh, Li-ion, Up to 40-hour talk time
Compatibility
Yealink W70B, Yealink W80, Yealink W90
Frequency Range
1880 MHz to 1900 MHz (EU), 1920 MHz to 1930 MHz (US)
USB Ports
2, USB 2.0 Type-A
Ethernet Ports
10/100M Ethernet Switch, Two-port
