Crestron HD-MD8X8-4KZ-E مبدّل AV بدقة 4K60 4:4:4 HDR، 8 مداخل HDMI و8 مخارج HDMI، HDR10 وHDR10+ وDolby Vision

Crestron HD-MD8X8-4KZ-E 8x8 4K60 4:4:4 HDR AV Switcher Specifications: MANUFACTURER: Crestron MODEL: HD-MD8X8-4KZ-E REGULATORY MODEL: M201946002 HDMI IN 1-8: (8) HDMI digital video/audio inputs (DVI & Dual-Mode DisplayPort interface compatible) HDMI OUT 1-8: (8) HDMI digital video/audio output (DVI compatible) AUDIO OUT, AUX 1-2: (2) 5-pin 3.5 mm detachable terminal block; Balanced/unbalanced stereo line-level audio output LAN: (1) 8-pin RJ-45 female; 100BASE-TX/1000BASE-T Ethernet port 24 VDC, 2.5 A: (1) 2.1 x 5.5 mm DC power connector; 24 VDC power input; ( PW-2420RU Power Pack included) SERVICE: (1) USB Type A female; For firmware loading and configuration management; Can also provide up to 5 V 500 mA power to USB powered device G: (1) 6-32 screw, chassis ground lug DIMENSIONS: 44 mm × 441 mm (without rack ears) × 179 mm WEIGHT: 5.15 lb (2.37 kg) The HD-MD8X8-4KZ-E is a 4K60 4:4:4 HDR (High Dynamic Range) AV switcher that provides a cost-effective solution for professional AV applications. Equipped with eight HDMI® inputs and eight HDMI outputs, the HD-MD8X8-4KZ-E includes features such as EDID management, HDCP 2.3 compliance, enterprise-grade security, and XiO Cloud® service support. Crestron HD-MD8X8-4KZ-E HDMI AV Switcher Features: 4K60 4:4:4 digital AV switcher. HDR10, HDR10+, and Dolby Vision® video formats. Eight HDMI® inputs and eight HDMI outputs. EDID management. HDCP 2.3 compliance. HDMI audio de-embedding. Device control via CEC. Enterprise-grade security. Built-in web interface. Compatibility with Crestron® 3-Series® or later control systems. AV Framework™ technology support. XiO Cloud® service support. 1 RU rack-mountable design 100-240 VAC power pack included. Crestron HD-MD8X8-4KZ-E 8x8 4K60 4:4:4 HDR AV Switcher Resources: Crestron HD-MD8X8-4KZ-E Spec Sheet: View PDF
