Shure Microflex MXN-AMP – مكبّر مدعوم بـ PoE+، 4 مداخل و4 مخارج Dante، مدخل غير متوازن، مدخل منطقي

Shure Microflex® MXN-AMP PoE+ Powered Multichannel Amplifier Specifications: Manufacturer: Shure Model: MXN-AMP Connector Type: Logic Input: 3-pin connector, 0.2 in. (5.08mm) pitch, Dinkle 2ESDV-03P LoZ Output: 2-pin connector, 0.2 in. (5.08mm) pitch, Dinkle 2ESDV-02P 70V Output: 2-pin connector, 0.295 in. (7.5mm) pitch, Dinkle 7ESDV-02P Audio Inputs: 4× Dante in, 1× 3.5 mm TRS connector with two audio line level inputs Control Input: logic in Audio Outputs: 4× Dante outputs, 4× LoZ loudspeaker outputs, 1× 70V loudspeaker output Output Power Per Channel: LoZ Mode: 3.25W,  70V Mode: 11.7W Power Input: Power over Ethernet (PoE) or PoE+ over RJ45 (48 V = 25.5 W MAX) Weight: 2.43 Ibs (1.1kg) Product Dimensions: 7.95 x 7 x 1.57 in. (202 x 178 x 40 mm) L x W x H Control Software: Shure Designer Digital Signal Processing: Gain/Mute, Delay, EQ, Limiter, Speaker Presets Latency: 2.2 ms typical, 2.5 ms max (add 1 ms for Dante Multichannel PoE+ powered amplifier designed for speech and program audio reproduction in meeting rooms. When used with Microflex Ecosystem microphones, DSP, and loudspeakers, they deliver room-filling sound, quick installation in a variety of room types, end-to-end audio encryption, and the efficiency of a single-source solution. Shure Microflex® MXN-AMP PoE+ Powered Amplifier Features: Provides power for up to 4 MXP loudspeakers in 8 ohm mode, or up to 8 MXP-5/MXP-6 loudspeakers in 70V mode. Rated at 14.5 watts of combined output power Four Dante inputs and four Dante outputs. Unbalanced stereo analog audio input. Logic input (switches between presets 1 and 2 as defined in web UI). Onboard Shure DSP utilities include EQ, delay, limiter, and signal/tone generator. Presets for all MXP-series loudspeakers ensure optimal audio performance. Custom presets can be defined in the MXN-AMP web-based control software. Rack mountable with available CRT-1 rack tray and wall or ceiling mounted (Note: Shure recommends the use of an additional safety tether for overhead components.). Supports standards-based security protocols to manage access and protect data, including 802.1x, secure boot/storage, and AES encryption for control and audio data. Seamless connectivity and compatibility with popular collaboration platforms, including Microsoft Teams and Zoom. Shure Microflex® MXN-AMP PoE-Powered Multichannel Amplifier Resources: Shure MXN-AMP Datasheet: View PDF
