Crestron CEN-SWPOE-26 محوّل شبكة بـ26 منفذ PoE+، محوّل شبكة إضاءة من NETGEAR رائد في فئته

Crestron CEN-SWPOE-26 PoE+ Network Switch Specifications: Manufacturer: Crestron Model: CEN-SWPOE-26 Ports: (2) 10/100/1000Base-T auto-sensing Gigabit Ethernet; (24) 10/100/1000Base-T auto-sensing Gigabit Ethernet w/PoE+; (4) 1 Gigabit Base-X SFP Network Standards: IEEE 802.3af, 802.3at MAC Addresses: Up to 16K Switch Fabric: 60 Gbps non-blocking Connectors: OOB: (1) 8-wire RJ45, female; 10/100/1000Base-T Ethernet port 1-24: (24) 8-wire RJ45, female; 10/100/1000Base-T Ethernet ports and PoE Power Sourcing Equipment (PSE) outputs; Supports IEEE 802.3at Type 2 PoE+ power sourcing from any ports up to the maximum specified power capabilities; Maximum 30 Watts per port, 300 Watts total 25-26: (2) 8-wire RJ45, female; 10/100/1000Base-T Ethernet ports 27-30: (4) SFP ports, female; 1 Gigabit Base-X SFP Chassis: Metal, black finish, fan-cooled, vented sides Mounting: Freestanding or 1U 19-inch rack-mountable with reversible rack ears Main Power: 4.4 Amps @ 100–240 Volts AC, 50/60Hz Power Consumption: Max PoE: 401 W; No PoE: 35.8 W; Standby: 23.4 W This class-leading NETGEAR® network switch is designed to make integration with Crestron commercial lighting products as simple as possible. The CEN-SWPOE-26 is a 26 port managed Ethernet switch that provides PoE+ from 24 of its ports. Easily mount the CEN-SWPOE-26 in a lighting enclosure or 19 in. rack to provide an Ethernet connection with no configuration required. A Web browser interface and an advanced command line are available for complex systems. PoE+ is supplied simultaneously across 24 ports, providing a centralized power source for numerous PoE+ powered devices and eliminating the need for cumbersome power supplies and extra wiring. Up to 30 W is provided per port up to a combined maximum output of 300 W. Crestron CEN-SWPOE-26 26 Port PoE+ Network Switch Features: Class-leading NETGEAR® lighting network switch. 26 port managed switch. Lighting enclosure or 19 in. rack mountable. Twenty-six 1000Base-T Gigabit Ethernet ports. Supports PoE+ (802.3at Type 2) on 24 Ethernet ports. Provides up to 30 W per port, maximum 300 W combined output. Layer 2 and Layer 3 managed switching functionality. LLDP (Link Layer Discovery Protocol) support. 60 Gbps switching fabric (non-blocking). Crestron CEN-SWPOE-26 26 Port PoE+ Network Switch Resources: Crestron CEN-SWPOE-26 Spec Sheet: View PDF
