Crestron CEN-SWPOE-ULTRA-12 محوّل شبكة مُدار بـ12 منفذ Ultra PoE، محوّل شبكة AV من NETGEAR رائد في فئته

Crestron CEN-SWPOE-ULTRA-12 PoE++ Managed Switch Specifications: Manufacturer: Crestron Model: CEN-SWPOE-ULTRA-12 Ports: (2) 10/100/1000Base-T auto-sensing Gigabit Ethernet; (8) 10/100/1000Base-T auto-sensing Gigabit Ethernet w/PoE++; (2) 10 Gigabit Base-X SFP+ Network Standards: IEEE 802.3af, 802.3at, 802.3bt MAC Addresses: Up to 16K Switch Fabric: 60 Gbps non-blocking Connectors: OOB: (1) 8-wire RJ45, female; 100/1000Base-T Ethernet port CONSOLE: (1) 8-wire RJ45, female USB-C: USB-C® port, female 100-240V: (1) power connector USB: USB Type A, female LED EXT: USB-C® port, female 1-8: (8) 8-wire RJ45, female; 10/100/1000Base-T Ethernet ports and PoE Power Sourcing Equipment (PSE) outputs; Supports IEEE 802.3bt Type 3 PoE++ power sourcing from any ports up to the maximum specified power capabilities; Maximum 90 W per port, 720 W total 9-10: (2) 8-wire RJ45, female; 100/1000Base-T Ethernet ports 11-12: (2) SFP+ ports, female; 10 Gigabit Base-X SFP+ Chassis: Metal, black finish, fan-cooled, vented sides Mounting: Freestanding or 1U 19-inch rack-mountable with reversible rack ears Main Power: 10A @ 100–240VAC, 50/60 Hz Power Consumption: Max PoE: 837.7 W; Full Mesh Traffic, No PoE: 26.3 W; Standby: 18 W Class-leading NETGEAR® AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN-SWPOE-ULTRA-12 is a 12 port managed Ethernet switch that provides PoE++ from eight of its ports. The two 10 Gigabit Base-X SFP+ ports enable use of transceiver modules to connect to a fiber network. Crestron CEN-SWPOE-ULTRA-12 12 Port Ultra PoE Managed Switch Features: Class-leading NETGEAR® AV network switch. Rack-mount 12 port managed switch. Ten 1000Base-T Gigabit Ethernet ports. Supports PoE++ (802.3bt Type 3) on eight Ethernet ports. Provides up to 90 W per port, maximum 720 W combined output. Two 10 Gigabit Base-X SFP+ ports. Selectable DM NVX® AV-over-IP and DM NAX® Audio-over-IP profiles. Layer 2 and Layer 3 managed switching functionality. LLDP (Link Layer Discovery Protocol) support. 60 bps switching fabric (non-blocking). Simple-to-use Web browser interface. Crestron CEN-SWPOE-ULTRA-12 12 Port Ultra PoE Managed Switch Resources: Crestron CEN-SWPOE-ULTRA-12 Spec Sheet: View PDF
