Crestron CEN-SWPOE-30 محوّل شبكة مُدار بـ30 منفذ PoE+، محوّل شبكة AV من NETGEAR رائد في فئته

Crestron CEN-SWPOE-30 PoE+ Network Switch Specifications: Manufacturer: Crestron Model: CEN-SWPOE-30 Ports: (2) 10/100/1000Base-T auto-sensing Gigabit Ethernet; (24) 10/100/1000Base-T auto-sensing Gigabit Ethernet w/PoE+; (4) 10 Gigabit Base-X SFP+ Network Standards: IEEE 802.3af, 802.3at MAC Addresses: Up to 16K Switch Fabric: 132 Gbps non-blocking Connectors: OOB: (1) 8-wire RJ45, female; 100/1000Base-T Ethernet port CONSOLE: (1) 8-wire RJ45, female USB-C: USB-C® port, female 100-240V: (1) power connector USB: USB Type A, female LED EXT: USB-C® port, female 1-24: (24) 8-wire RJ45, female; 10/100/1000Base-T Ethernet ports and PoE Power Sourcing Equipment (PSE) outputs; Supports IEEE 802.3at Type 2 PoE+ power sourcing from any ports up to the maximum specified power capabilities; Maximum 30 W per port, 480 W total 25-26: (2) 8-wire RJ45, female; 10/100/1000Base-T Ethernet ports 27-30: (4) SFP+ ports, female; 10 Gigabit Base-X SFP+ Chassis: Metal, black finish, fan-cooled, vented sides Mounting: Freestanding or 1U 19-inch rack-mountable with reversible rack ears Main Power: 6.4-2.5A @ 100–240VAC, 50/60 Hz Power Consumption: Max PoE: 614 W; Full Mesh Traffic, No PoE: 46.8 W; Standby: 33.9 W NETGEAR's class-leading AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN-SWPOE-30 is a 30 port managed Ethernet switch that provides PoE+ from 24 of its ports. The four 10 Gigabit Base-X SFP+ ports enable use of transceiver modules to connect to a fiber network. When configuring a DM NVX or DM NAX system, select the appropriate profile to automatically configure the CEN-SWPOE-30 with the multicast functionality required for AV-over-IP. Using a streamlined interface, quickly and completely configure individual ports or assign AV profiles for use with DM NVX or DM NAX systems. An advanced command line interface is also available. All SFP+ ports offer 10 Gigabit Base-X connections with support for both multimode and single-mode fiber transceiver modules, such as the SFP-10G-SR . PoE+ is supplied simultaneously across 24 ports, providing a centralized power source for numerous PoE+ powered devices and eliminating the need for cumbersome power supplies and extra wiring. Up to 30 W is provided per port up to a maximum of 480 W. Crestron CEN-SWPOE-30 30-Port PoE+ Network Switch Features: Class-leading NETGEAR® AV network switch. Rack-mount 30 port managed switch. Twenty-six 1000Base-T Gigabit Ethernet ports. Supports PoE+ (802.3at Type 2) on 24 Ethernet ports. Provides up to 30 W per port, maximum 480 W combined output. Four 10 Gigabit Base-X SFP+ ports. Selectable DM NVX® AV-over-IP and DM NAX® Audio-over- IP profiles. Layer 2 and Layer 3 managed switching functionality. LLDP (Link Layer Discovery Protocol) support. 132 Gbps switching fabric (non-blocking). Simple-to-use Web browser interface. Crestron CEN-SWPOE-30 30 Port PoE+ Network Switch Resources: Crestron CEN-SWPOE-30 Spec Sheet: View PDF
